Hull Design and Fairing Level 1&2 Bundle – Live

Hull Design and Fairing Level 1&2 Bundle – Live

 945,00

Live Online Training – M0R1 + M1R1 + M1R2

SKU: OT-Bundle-Hull Design and Fairing 1&2-live Categories: , ,

Description

Rapid Hull Modeling for: Ships / Yachts / Workboats / Multihulls

Class-A Fairing – Final Design – Fairing for Production – Hull Optimization – Reverse Engineering – Hull from GA/ Lines-Plan – Advanced Analysis – Modeling Strategies – Developable Hulls

Live online training intensive of ‘Hull Design and Fairing Level 1&2’

Edition one: October 4 – 25 (CEST): 09:00 – 11:00 h.

Edition two: November 4 – 25 (CET): 16:00 – 18:00 h.

Follow and finish this training now within one month.

  • Three training modules are covered in four live training sessions of two hours. In between the live sessions you practice the exercises as self-study with the instructional videos and written out exercises.
  • For trainees around the world, the four live sessions are offered in two editions. Check which edition suits you best depending on your schedule and time zone. When you purchase this training, please send an email to tell us for which edition you apply.
  • October edition-1 live sessions; Central European Summer Time (CEST): 09:00 – 11:00 h:
    • week 40, on October 4 – CEST 09:00 – 11:00 h.
    • week 41, on October 11 – CEST 09:00 – 11:00 h.
    • week 42, on October 18 – CEST 09:00 – 11:00 h.
    • week 43, on October 25 – CEST 09:00 – 11:00 h.
  • November edition-2 live sessions; Central European Time (CET): 16:00 – 18:00 h:
    • week 45 on November 4 – CET 16:00 – 18:00 h.
    • week 45 on November 11 – CET 16:00 – 18:00 h.
    • week 45 on November 18 – CET 16:00 – 18:00 h.
    • week 45 on November 25 – CET 16:00 – 18:00 h.
  • After purchasing the training you can immediately start exercising and follow the live sessions at a later time.
  • The covered training modules are:
    • M0R1 – Prepare2d input is about 4 hours of practice
    • M1R1 – Hull Design and Fairing Level-1 is about 8 hours of practice
    • M1R2 – Hull Design and Fairing Level-2 is about 10 hours of practice
  • Maximum of 10 participants per session. The training is postponed when we have less than three trainees.
  • The trainer is Gerard Petersen, one of the developers of the method is a naval architect and fairing professional.
  • After sending in some tasks, you receive a certificate of completion.
  • There is an option for 1-4 hours extra personal training support hours.
  • To kickstart your hull modeling and fairing jobs there are two extra support programs of 8 hours or 16 hours.
  • Please contact Gerard Petersen for more information and receiving the detailed schedule and program.

Students and Teachers pay €375 for this training. It is compulsory to send proof of your status to Gerard Petersen. After that you’ll receive a coupon discount code.



bulbous bow hullaft bulb hullheavy lift hulltug boatsail yachtplaning hull with tunnelsworkboat developableplaning hull with spray rail

Rhino enables accurate, flexible and fair vessel hull design with the “Rapid Hull Modeling Methodology”.
This method is developed by RhinoCentre in co-operation with other professionals in the marine industry.
After years of offering training and services to leading companies in the marine industry worldwide, RhinoCentre developed three unique training modules.

Buy now these three unique training modules as a bundle with a discount:

This training will unveil the mystery of Class-A fairing to any designer, engineer, naval architect and shipyard.

Testimonial

“I feel Gerard’s live training was very valuable not just for the Rhino information and CAD file preparation he shares but more so for the years of experience in hull design which inform his modeling approach. With a friendly and patient manner he engages you in the process as opposed to simply reporting how it’s done, he’s an inspiring teacher!”

Lauren Lake, Instructor | IYRS School of Technology & Trades

  • This is a pure Rhino 5, Rhino 6 or Rhino 7 software training. Plugins are not required.
  • Total training duration of the three modules: 24 hours.
  • Mandatory prerequisites for this training: R1L1 – Rhino Level 1 training or a couple of months working with Rhino.
  • After purchasing this module, it will be accessible and available for twelve months.
  • It is possible to save the texts and images of the training module as a reference book. The instructional movies will not be available anymore when the access period ends.
  • By purchasing this product, one person is allowed to follow this training. This means that, for example, a colleague should also purchase this training. We trust you in this and ask you to respect our efforts and investment in developing this training for you.

Down below, you can see a small part of the online training to give you an idea what you can expect.

First, every exercise is explained with a movie. After that, below the movie, the exercise is written out step by step so you can practice yourself. You also receive tips, cautions and notes to understand better what you do and learn more than is explained in the exercises.

Exercise 10: Add an extra loft curve (Part 2/3)



Exercise 10: Fit the loft surface to the original GA within tolerance and fair (Part 3/3)



Exercise 10: Fit the loft surface to the original GA within tolerance and fair

  • Turn on the layers “Reference curves”, “+175 mm” and “-175 mm”
  • Start editing the bulb shape loft curves as that part is most off from the ref-ribs. use _Move, _Scale, _Nudge, etc. whatever is convenient to you. Add loft curves if needed
  • Remember to use the checklist above regularly while editing
  • Save your file in the WIP folder on your desktop.

Homework: Now transform the aft ship yourself. When you purchased online support, please mail the result to your contact person for feedback.

In the training files folder you can find the file M1R2-3D-AHTS Hull-Result.3dm. This shows an example of a fair and accurate result.
